Description
 |  |  |
| The machine frame uses an integrated wall panel structure, pin positioning, the whole machine is more stable, and the printing is more accurate | The carriage movement adopts 750W AC servo motor and reducer to ensure the stability of continuous work | Double-row infrared heating and professional external rewinding system ensure the picture drying fast with high-speed printing, convenient for post picture processing |
 |  |  |
| With negative pressure system, ink supply is more stable and ink saving | With double guide rails, the carriage moves more smoothly | The print head anti-collision system can effectively prevent head damage during printing. |
 |  |  |
| Adopting reflective photoelectric switch, capable of printing on black light cloth | Electric pinch roller | Material guide device, material collection is more smooth |
Additional Information
| Model | E12 |
| Head Model | KM512I-30PL |
| Printhead quantity | 12 |
| Printing speed | 2PASS，360X360dpi，450m2/h 3PASS，360X540dpi，312m2/h 2PASS，480X360dpi，350m2/h 3PASS，480X540dpi，240m2/h |
| Drop volume | 30PL |
| Drying system | Infrared- heater fan |
| Print width | 3350mm |
| Rp software | UltraPrint/MainTop/Photo Print/PrintFactory |
| Electricity requirement | 220v/40A/50HZ & 380V/30A |
| Machine max power | 14545W |
| Printing system | 1845W |
| Front&rear heater | 4300W |
| Infrared heater | 8400W |
| Machine package size | 5870(L)*1300(W)*2100(H)mm |
| Machine body size | 5675(L)*1260(W)*1680(H)mm |
| Gw（kg） | 1500KG |
| Nw（kg） | 1300KG |
*Specifications are subject to change without prior notice, all rights reserved
