Description
 | Imported high precision track |  | High quality DC servo motor with good stability and long service life |
 | Standard equipped with intelligent infrared heating and air drying system |  | External power supply, intelligent paper collecting system, the feeder will automatically start and shut down as the machine prints and stops, extending the service life of the feeder motor |
 | Automatic moisturizing cleaning module ensures the cleaning and working stability |  | Print heads collision avoidance system can effectively prevent the head from crashing during printing |
Additional Information
| Mode | E1802 / E1804 | |||
| Head Model | EPSON I3200-A1 | EPSON F1440-A1 | ||
| Ink Model | CMYK | |||
| Wide Application | Indoor and outdoor PP and photo paper, car sticker, water – based backlit film, eco-solvent lamp, canvas, non-wovenCloth, digital printing materials, etc. | |||
| Print width | 1.8M | |||
| Medium | Width：1.8M Thickness：1MM Weight：60KGS | |||
| Ink cartridge | Type：Solvent/water-based/SublimationVolume：220cc 2ndcartridge +3.0L Big volume ink-bottle with float Color：Four Color | |||
| Printing resolution | EPSON I3200-A1（Maximum 1440dpi） | EPSON F1440-A1（Maximum 2400dpi） | ||
| Head qty | 2PCS | 4PCS | 2PCS | 4PCS |
| Printing speed | 3pass:60m2/h 4pass:42m2/h 6pass:30m2/h | 3pass:120m2/h 4pass:84m2/h 6pass:60m2/h | 3pass:44m2/h 4pass:32m2/h 6pass:22m2/h | 3pass:88m2/h 4pass:64m2/h 6pass:44m2/h |
| Size | 3150mm*725mm*1480mm (Two heads) | 3154mm*1038mm*1720mm (Four heads) | ||
| Net Weight | 370 KGS (Two heads) | 400KGS (Four heads) | ||
| Wooden box package | Separate package : 3350mm*750mm*968mm (Two heads ) | 3350mm*750mm*968mm (Four heads) | ||
| Gross Weigh | 420 KGS (Two heads) | 450KGS (Four heads) | ||
| Heating system | Integrated heater, infrared dryer and fan system | |||
| Interface | USB2.0 | |||
| Power | AC220V,50/60HZ | |||
