Description
 |  |  |  |
| Equipped with intelligent infrared heating system, the picture is dried in time | Increase print head anti-collision system, effectively prevent head damage during printing. | Standard automatic colleting system | Unique ink stack printhead protecting device |
 | |||
| Three feeding methods can be selected according to needs: Insert type, two-roller deposit type, three-roller dragging deposit type | |||
 |  | ||
| The secondary ink cartridge is heated, and the head plate is heated | Three-stage heating | ||
Additional Information
| Model | C8 |
| Head Model | KM512I-30PL |
| Printhead quantity | 8 |
| Printing speed | 2pass，360×360dpi，280m2/h 3pass，360×540dpi，180m2/h 2pass，480×360dpi，240m2/h 3pass，480×540dpi，140m2/h 4pass，480×720dpi，110m2/h |
| Drop volume | 30PL |
| Drying system | Infrared- heater fan |
| Print width | 3300mm |
| Rip software | UltraPrint / MainTop / Photo Print / PrintFactory |
| Electricity requirement | 220v/60A/50HZ |
| Machine max power | 9095W |
| Printing system | 1145W |
| Front&rear heater | 3750W |
| Infrared heater | 4200W |
| Machine package size | 4700(L)*1030(W)*1570(H)mm |
| Machine body size | 4450(L)*940(W)*1300(H)mm |
| Gw（kg） | 975KG |
| Nw（kg） | 875KG |
*Specifications are subject to change without prior notice, all rights reserved
