Description
 |  |  |
| The pinch roller assembly adopts the Eco solvent machine pinch roller structure, which makes the stepping more precise, the stitching is more perfect, and the fan power is larger | Intelligent infrared drying system, printing start/stop, infrared automatic open and close | The feeding system adopts built-in cloth stuck structure to prevent the material from deviation |
 |  |  |
| Standard negative pressure system, continuous printing without ink losing | Adopting reflective photoelectric switch, capable of printing on black light cloth | The print head anti-collision system can effectively prevent head damage during printing |
Additional Information
| Model | C8 PLUS | |
| Head Model | KM-HS1000 | KM512I-30PL |
| Printhead quantity | 8 | |
| Printing speed | 1pass，360×360dpi，600m2/h 1pass，480×360dpi，480m2/h 2pass，360×720dpi，280m2/h 2pass，480×720dpi，240m2/h | 2pass，360×360dpi，280m2/h 3pass，360×540dpi，180m2/h 2pass，480×360dpi，240m2/h 3pass，480×540dpi，140m2/h |
| Drop volume | 30PL | |
| Drying system | Infrared- heater fan | |
| Print width | 3300mm | |
| Rp software | UltraPrint / MainTop / Photo Print / PrintFactory | |
| Electricity requirement | 220v/60A/50HZ | |
| Machine max power | 13295W | 9095W |
| Printing system | 1145W | 1145W |
| Front&rear heater | 3750W | 3750W |
| Infrared heater | 8400W | 4200W |
| Machine package size | 5000(L)*1050(W)*1630(H)mm | |
| Machine body size | 4840(L)*940(W)*1400(H)mm | |
| Gw（kg） | 1135KG | |
| Nw（kg） | 1035KG | |
*Specifications are subject to change without prior notice, all rights reserved
