Description
Brand New tension feeding &collecting system
Fessional color management software
Brand New environment protecting ink system
◆ ALLWIN “Vivid color” Series use eight color printing, to acquire higher printing resolution and bright colors
◆ Brand New tension feeding & collecting system, can achieve 10 meters stitching◆ without error when printing light box
◆ New mechanical design concept, improved printing resolution, printing performance ◆ rivals the imported machine of its type
Additional Information
| Model | AW-EP19 Eight Color printer | |
| Head Model | EPSON I3200-A1 | EPSON F1440-A1 |
| Printhead quantity | Eight heads | |
| Ink Model | CMYK | |
| Wide Application | Indoor and outdoor PP and photo paper, car sticker, water – based backlit film, eco-solvent lamp, canvas, non-wovenCloth, digital printing materials, etc. | |
| Medium | Width：1.9m
Thickness：1.8mm Weight：60KG |
|
| Print width | 1.9m | |
| Ink cartridge | Type：Solvent/water-based/Sublimation
Volume：220cc 2ndcartridge +3.0L Big volume ink-bottle with float Color：Eight Color |
|
| Printing speed | 3pass: 120m2/H
4pass: 84m2/H 6pass: 60m2/H |
3pass: 88m2/H
4pass: 64m2/H 6pass: 44m2/H |
| Size | 3710MM*855MM*1950MM | |
| Net Weight | 560 KG | |
| Wooden box package | Separate package 3900mm×1080mm×1170mm | |
| Gross Weigh | 650KG | |
| Heating system | Integrated heater, infrared dryer and fan system | |
| Interface | USB3.0 | |
| Power | AC220V,50/60HZ | |
| Working Environment | Power on Temperature 18℃-28℃
Power off Humidity 40%-60% |
|
*Specifications are subject to change without prior notice, all rights reserved
