Description
 | Imported THK high accuracy mute track |  | High quality DC servo motor with good stability and long service life |
 | Standard equipped with intelligent infrared heating and air drying system |  | It can print whole roll with 3.2m width material, especially suitable for the production of high-precision inkjet cloth. Two rolls 1.27m width material can be printed at the same time (air-expansion shaft feeding & collecting system can be choose for the special textile material) |
 | Automatic moisturizing, cleaning module ensures the, cleaning and working stability |  | Print heads collision avoidance system can effectively prevent the head from crashing during printing |
Additional Information
| Model | E3204 | E3208 | |||
| Head Model | EPSON I3200-A1 | EPSON I3200-E1 | |||
| Ink Model | CMYK | ||||
| Wide Application | Indoor and outdoor PP and photo paper, car sticker, water – based backlit film, eco-solvent lamp, canvas, non-wovenCloth, digital printing materials, etc. | ||||
| Print width | 3.2M | ||||
| Medium | Width | 3.2M | |||
| Thickness | 1MM | ||||
| Weight | 120KGS | ||||
| Ink cartridge | Type | Solvent/water-based/Sublimation | |||
| Volume | 440ml cartridge +5.0L Big volume ink-bottle with float | ||||
| Color | Four Color | ||||
| Printing resolution | EPSON I3200-A1（Maximum 1440dpi） | EPSON I3200-A1（Maximum 1440dpi） | |||
| Head qty | 2PCS | 4PCS | 6PCS | 8PCS | |
| Printing speed | High Speed 60m2/h High Precision 46m2/h | High Speed 117m2/h High Precision 92m2/h | High Speed 160m2/h High Precision 120m2/h | High Speed 195m2/h High Precision 160m2/h | |
| Size | 5164MM*1295MM*1990MM | ||||
| Net Weight | 855KGS | ||||
| Wooden box package | 5600MM*760MM*1270MM | ||||
| Gross Weigh | 935KGS | ||||
| Interface | USB2.0 | ||||
| Heating system | Integrated heater, infrared dryer and fan system | ||||
| Power | AC220V,60A/50HZ | ||||
